10/100/1000 Ethernet Solution
Test standard:IEC 61000-4-2：±8KV（contact）±15KV(air); ITU-TK.21：10/700uS 6KV/40Ω ±5 times，Interval: 60S
-
10/100/1000 Ethernet ESD Prote
The data signals used in an Ethernet port typically vary between 1.0V and 2.5V, with maximum data rate of 1000Mbps (or 1Gb). Some 10GigE applications are also s...
-
MMC Interface
For typical Multi Media Card (MMC) circuits, the data transfer rate is less than 20 Mbps, so protection devices with capacitance values less than 40 pF can be u...
-
HDMI Port
The data signals used in High Definition Multimedia Interface ports vary between approximately 2.5V and 3.5V, and have a data rate of 1.6Gbps (1.3) or 3.4Gbps (...
-
USB2.0 Port
The maximum transfer rate of USB2.0 is 480Mbps. Signal lines to be protected from ESD include D+ and D-. The 5VDC power bus also needs to be protected from ESD ...
-
USB3.0 Port
The maximum transfer rate of USB3.0 is 5Gbps.
-
VGA Port
The maximum frequency of the signal lines used for VGA port is 25MHz, and the video signals of its R, G, and B lines are 0.7Vp-p, and the video signals of ID01,...
-
eSATA Port
The transfer rate of eSATA port is 1500 Mbps (Gen 1), 3000 Mbps (Gen II). Lines to be protected are Rx+, Rx-, Tx+ and Tx-.
-
Keypad/Buttons
The keypads and various buttons found on a cell phone can be an entry way for ESD. These circuits are low-voltage DC switches, typically less than 5VDC.
